20-30CPM Semi-Automatic Hydraulic-Drive Square Canbody Forming Machine GT3F3Y for 1-5L Square/Rectangle Tin Can Making

产品编号:

1051283945632391168

Operation:

Semi-Automatic

Can Size:

1-5L Square Can

Speed:

Operator Dependent

Line Dimension:

L720 x W1,400 x H1,500 (mm)

Line Weight:

400kg Approx.

keyword:

square can forming machinie

square can expanding machine

tin can expanding machine

square can expander

tin can making machinery


Product Overview

Square Canbody Expanding Machine
Message
Feature Workflow BOM Technical Parameter YouTube Video PDF Download

20-30CPM Semi-Automatic Hydraulic-Drive Square Canbody Forming Machine GT3F3Y for 1-5L Square/Rectangle Tin Can Making

Model GT3F3Y
Usage 1-5L Square-forming Canbody for Canmaking
Operation Model Semi-Automatic Hydraulic
Main Color White
Output Capacity (CPM) 20-30cans/min.
Applicable Can Shape Square
Applicable Can Vol. 1-5L
Support Canbody Material Tinplate / Steel-based / Chrome
Canbody Material Hardness T2.5-DR8
Canbody Max. Thickness 0.4mm
Main Frame Material High Strength Steel for Canmaking
Forming Die Sets Changeable Function Provided
Built-in Dual-forming Die Function Provided (upon request, only one working at the same time)
Motor 3kw
Power Supply Required 380V 50/60Hz @ Three-Phase Sys.
Power System Overload & Short-Cuit Protection Provided
Pad-Lock Emergency Switch (ON-OFF) Built-in
Protection Grade for Electrical Switch-gear Box Class Index IP65
Standard IEC60947 for Electrical System
Motor Supplier SIEMENS
Electrical Control & Distribution System Supplier Schneider Electric
Construction Size 720 x 1400 x 1500 (mm)
Weight 400kg
Shipment Lead time: 3-4weeks
Packaging Plywood Case (Standard Export Packaging)
Warranty: 1st Year FREE CHARGE for parts from shipping date + Lifetime services
Operator Manual & Instruction DVD supplied
