Automatic Canbody Roll Bending Machine for Rectangle Can Making

Perfect Match with Rear feeding type welder.
Retail price
0.0
Market price
0.0
Number of views:
1009
Product serial number
Quantity
-
+
Stock:
Operation:
Automatic
Can Size:
D70-180(mm) / D99-300(mm) / D52-180(mm)
Speed:
up to 120 CPM
Line Dimension:
L2,100 x W720 x H1,520 (mm)
Line Weight:
350kg Approx.
1
Feature
Parameters
Workflow
BOM
Technical Parameter
YouTube Video
PDF Download

Automatic Canbody Roll Bending Machine for Rectangle Can Making

Model ZDJY80-330 ZDJY45-450 ZDJY120-320 ZDJY120-280
Usage Automatic Roll-forming Canbody for can making
Operation Mode Automatic Feed-in and roll-forming

Output Capacity(CPM)

10-80cans/min 5-45cans/min 30-120cans/min 30-120cans/min
Range of Can Diameter 70-180mm 99-300mm 52-180mm 52-180mm
Range of Can Height 70-330mm 100-450mm 70-320mm 70-280mm
Support Canbody Material Tinplate / Steel-based / Chrome
Canbody Material Hardness T2.5-DR8
Canbody Thickness Range 0.15-0.42mm 0.15-0.35mm
Compressed Air Consumption 200L/min 600L/min
Pressure of Compressed Air 0.5-0.7Mpa

Power System Overload &

Short-Circuit Protection

Provided

Protection Grade for Electrical

Switch-gear Box

Class Index IP65
Standard IEC60947 for Electrical System
Motor Power 2.2kW 1kW
Power Supply Required 380V 50/60Hz @ Three-Phase Sys.
Weight 350kg 350kg 350kg 340kg
Construction Size 2100 X 720 X 1520 (mm) 2100 x 1000 x 1400 (mm) 700 x 1100 x 1200(mm) 650 x 1100 x 1200(mm)
Shipment Lead time: 2-4 weeks 2-4 weeks 2-4 weeks 2-4 weeks
Packaging Plywood Case (Standard Export Packaging)
Warranty: 1st Year FREE CHARGE for parts from shipping date + Lifetime services

Operator Manual &

Instruction

PDF /  Printed paper provided



Keyword:
can roll forming machine
round can forming machine
steel pail can making machine
square can making machinery
tin can making
