Automatic Lock Seam Canbody Making Machine

Fancy Can Making Combo Machine
Retail price
0.0
Market price
0.0
Number of views:
1006
Product serial number
Quantity
-
+
Stock:
Operation:
Automatic
Can Size:
D50-310(mm)/ Diagonal up to 230 X 230(mm), H50-320(mm)
Speed:
25-50cpm (Size Dependent)
Line Dimension:
Details See Chart Below
Line Weight:
2,000kg / 2,800kg Approx.
1
Feature
Parameters
Workflow
BOM
Technical Parameter
YouTube Video
PDF Download

Automatic Lock Seam Canbody Making Machine

Model CBM200 CBM300
Usage Automatic Lock-seam Tin Can Body Making
Item Condition Brand-new Brand-new
Operation Mode Fully Automatic Pneumatic-Drive
Output Capacity (CPM) 25-50 cans/Min.
(Tin Can Size Dependent)
25-30 cans/Min.
(Tin Can Size Dependent)
Size for Round-shape Tin Can Φ50-190 (mm) Φ100-310 (mm)
Size for Square-shape Tin Can 70 X 70(mm) - 140 X 140 (mm) 100 X 100(mm) - 230 X 230 (mm)
Height Range of Tin Can 50-320 (mm)
Thickness of Tinplate 0.16-0.38 (mm)
Touch Panel Screen Device Built-in 7'' Color Display (English Language Interface) Built-in 7'' Color Display (English Language Interface)
PLC Device Built-in Built-in
VFD Device Built-in Built-in
Double-Check Detection Device Built-in Built-in
Auto Control Lub-Sys.  Built-in Built-in
Auto Feed-in Device Built-in Built-in
Auto Notching Function Provided Provided
Notching Die Fast-Change Function Provided Provided
Auto Pre-Curling Function Provided Provided
Auto Edge Hemming Function Provided Provided
Auto Lock-Seam Function Provided Provided
Lock-Seam Die Fast-change Function Provided Provided
Manual Operation Settable Function Provided Provided
Power System Overload & Short-Circuit Protection Provided Provided
Protection Grade for Electrical Switch-gear Box Class Index IP65 Class Index IP65
Standard IEC60947 for Electrical System
Total Power 7kW 7kW
Power Supply Required 380V AC 50/60Hz @ Three-phase Sys.
Weight 2000kg 2800kg
Construction Size 3000 X 2500 X 1600 (mm) 3200 X 3100 X 2000 (mm)
Lead time: 10-14 weeks from ordering
Packaging Plywood Case (Standard Export Packaging)
Warranty: 1st Year FREE CHARGE for parts from shipping date + Lifetime services
Operator Manual & Instruction PDF / Printed paper provided
