Semi-Automatic Single Gang Stlitter Machine for Chemical Round Can Making

The circular knives are made from SKD-11 alloy steel (JIS Standard/GB Standard/DIN Standard), giving excellent cutting effects and maximum wearing resistance.
Retail price
0.0
Market price
0.0
Number of views:
1002
Product serial number
Quantity
-
+
Stock:
Operation:
Semi-Automatic
Can Size:
Various
Speed:
Operator Dependent
Line Dimension:
L1,500 x W1,600 x H1,105 (mm)
Line Weight:
1,100kg Approx.
1
Feature
Parameters
Workflow
BOM
Technical Parameter
YouTube Video
PDF Download

Semi-Automatic Single Gang Stlitter Machine for Chemical Round Can Making

The circular knives are made from SKD-11 alloy steel (JIS Standard/GB Standard/DIN Standard), giving excellent cutting effects and maximum wearing resistance.

Slitting Machine

Fundamentally, slitting machine encompasses strategic cutting, shearing and slitting tin plates into blanks.  From these blanks, the can body, lid and bottom can be obtained. Therefore, slitting is the essential stage for the can making process. The slitting is done per request, consequently, it is dependent on the material and size of the can body, lid and bottom that is needed.

The slitting process

It’s one of the most straightforward process as just a single operator is expected to operate the machine.  The machine fundamentally consists of a platform where the plates are put. Blades are grouped into two groups located opposite each other; these blades are mounted on two drive shaft driven by motor. Slitting is performed by the rotating bladed disks. The blades are safeguarded for safety of the operator. Blank width is determined by the distance between each two blades.

A switch strategically fitted on the machine to help in turning on and off the machine. It has an extremely simple to use switch and no one needs intense training to effectively use the machine. When it comes to the actual shearing process, the operator inserts the plate into the blade groups. The tin plate passes through the rotating blade groups and is sheared into proper size blanks. Operator has to do this cautiously preventing his hands from injury.

Feature:

§  The slitting machine has a compact framework and structure to ensure it covers a small area in the working space. Thus allowing more area for other manufacturing processes.

§  The strong steel and other groundbreaking materials that are used to make the machine guarantee a long lasting and reliable production

§  It’s a fast working machine hence more blanks can be obtained at a brief timeframe

§  The machine is very easy to operate and an operator doesn’t need an intense training to know how to effectively use it.

§  The machine has a very low maintenance cost.

§  The machine allows different sizes of blanks to be obtained as few adjustments can be made.





This machine is used for cutting the tin plate sheets into strip and blanks for making tin cans or tin containers.

Tinplate Sheet Single Slitting Machine as the 1st step of can-making process, this machine is semi-automatic operated, simple design and consruction, easy to operate and maintentance. It own 8-group circle slitting dies for make 9 strips of metal sheet, tailor-made number of slitting die is provided.

Product Name

Tinplate Single Slitter

Usage

Tinplate Single Slitting for Canmaking

Model

GT1B5

Item Condition

Brand-New

Operation Mode

Semi-Automatic

Main Color

Silver

Output Capacity (CPM)

Operator Dependent

Feeding Mode

Manual Feed-in

Feeding Table Size

720 x 1300 (mm)

Main Frame Material

High Strength Steel

Slitting Method

Circular Knife

No. of Knifes (Slitting Die)

8-Group

Knife Material (Slitting Die)

High-grade Alloy Tool Steel (Cr12MoV)

Knife Adjustable Mode

Horizontal Sliding and Fixing

Support Materials

Tinplate / Steel-based

Max. Sheet Thickness

0.4mm

Max. Sheet Width

1050 - 1300 (mm)

Min. Sheet Width

55mm

Standard

IEC60947 for Electrical System

Safety

Machine Fully Guarded

Motor Power

1.1kw = 1.5HP

Motor Rotation Speed

900 RPM

Power Supply Required

380V 50/60Hz @ Three-Phase Sys

Motor Supplier

SIEMENS

Electrical System Supplier

Schneider

Net Weight

1100kg

Construction Size

1500 x 1600 x 1105 (mm)

Lead time:

3-4 weeks

Warranty

1st Year FREE CHARGE for parts from shipping date + Lifetime services

Packaging

Plywood Case (Standard Export Packaging)

Optional Extra

Knife Grinder

Operator Manual & Instruction

PDF / Printed Paper Provided

Service, Training & Replacement Parts are available from YONGXIN

Cutting capacity is limited by allowable number of knives on the machine.



Keyword:
gang slitter
tinplate sheet slitting machine
tinplate sheet slitter
tinplate sheet cutting machine
tinplate sheet cutter
