up to 600cpm D52-189(mm) 202# - 700# Low-level Palletizing Machine for Empty Food Can Making Line

Low-profile palletizer for food can making;

产品编号:

1051308882032156672

Model:

LFPT

Operation:

Automatic

Application:

Palletizing

Can size:

D52-189(mm)

Speed:

up to 600cpm

Classification:

keyword:

low profile palletizer

low frame palletizer

food can palletizer

milk powder can palletizer

tin can palletizer

palletizing


Product Overview

Message
Feature Workflow BOM Technical Parameter YouTube Video PDF Download

up to 600cpm D52-189(mm) 202# - 700# Low-level Palletizing Machine for Empty Food Can Making Line

LFPT series run fully automatically for palletizing or de-palletizing by using pushing and lifting mechanism. With optional configuration, this LFPT series can achieve the function of auto layer pad, pallet dispenser and pallet out feed. By connecting to inline stripper and  wrapper, it saves more manpower and increases production efficiency.

Model LFPT
Application metal can, plastic container, Glass Jar
Operation  Automatic
Output Speed up to 600CPM
Air Consumption 0.6MPa
HMI Device Built-in
PLC Device Built-in
Drying Mode Permanent Magnet Motor
Conveyor Feature Low-friction Chain
Standard Electrical Parts comply with IEC60947
Total Power 3.0KW
Machine Dimension L6,000 X W2,000 X H3,500 (mm)
Pallet Dimension L1,200 X W1,000mm (Tailor-made provided)



Ref. of Palletizing Via Pallet Size L1,200 x W1,000 (mm)
Can Code Cans Per Layer Speed Output
202# D52mm Necked 462 cans 600cpm
202# D52mm Straight 420 cans 500cpm
211# D65mm Necked 289 cans 370cpm
211# D65mm Straight 272 cans 350cpm
300# D73mm 225 cans 300cpm
307# D83mm 169 cans 220cpm
401# D99mm 121 cans 150cpm
404# D105mm 100 cans 130cpm
502# D127mm 70 cans 90cpm
603# D153mm 49 cans 60cpm
709# D189mm 33 cans 40cpm

palletizing machine layout
