GT2B3/2B5 Round Can End Edge Curling Machine
产品编号：
1051318093860397056
Model：
GT2B3/2B5
Operation：
Automatic
Application：
Curling
Can size：
D30-100(mm) / D100-170(mm)
Speed：
50-80epm
Classification：
keyword：
curling machine
curler
curling
disc curler
disc curling machine
tin can making machine
metal lid curling
can end curling
Product Overview
GT2B3/2B5 Round Can End Edge Curling Machine
Curling Lid/End edge, normally coordinate with punch press and connecting with gluing machine to make a complete set of automatic Lid/End production line for Tin Can Industry
Curl: The extreme edge of the end component which is turned inward after the edge is formed. The curl forms the cover hook in a double seam.
|
Model |
GT2B3 |
GT2B5 |
|
Round Lid/End Diameter |
30-100 (mm) |
100-170 (mm) |
|
Curling Die Material |
High-grade Alloy Tool Steel (Cr12MoV) |
|
|
Output Capacity (CPM) |
50-80 EPM |
|
|
Motor Power |
0.37kw |
|
|
Roated Speed |
270RPM |
|
|
Construction Size |
L1,100 X W740 X H590 (mm) |
L1,320 X W815 X H570 (mm) |
|
Machine Weight |
150kg |
200kg |
|
