Machines
FH18-65-III 20-80CPM Semi-Auto Can Body Seam Welder Machine
产品编号：
1051323373574774784
Model：
FH18-65-III
Operation：
Semi-Automatic
Application：
Seam Welding
Can size：
D65-176(mm); H70-420(mm)
Speed：
20-80cpm; 6-18Meters/Minute
Classification：
keyword：
welder
seam welder
seam welding machine
side seam welding
tin can making machine
Product Overview
FH18-65-III 20-80CPM Semi-Auto Can Body Seam Welder Machine
| Model | FH18-65-III |
| Usage | Canmaking Body Seam Welding for Dia. Range from Ø65-176mm |
| Item Condition | Brand-New |
| Operation Mode | Semi-Automatic |
| Feeding Type | Rear Manual |
| Welding Type | Resistance Seam Welding |
| Output Capacity (CPM) | 20-80cans/min. (Operator Dependent) |
| Seaming Rollers Materials | High-grade Alloy Copper |
| Main Color | White |
| Welding Speed | 6-18M./Min. |
| Range of Can Diameter | Ø65-176mm |
| Range of Canbody Height | 70-420mm |
| Support Canbody Materials | Tinplate / Steel-based |
| Canbody Thickness Range | 0.18-0.32mm |
| Seam Welding Overlap | 0.6mm / 0.8mm |
| Seam Point Distance | 0.5-0.8mm |
| Applicable Copper Wire Diameter | Ø1.38mm / Ø1.5mm (Purchased Separately Required) |
| Cooling Water | 20°C @ Pressure: 0.4~0.5Mpa Discharge:7L/min |
| PLC Device | Built-in (Provider MITSUBISHI) |
| Products Counts Function | Provided (On the Front Control Panel) |
| Emergency Stop Function | Provided (On the Front Control Panel) |
| Matching with Industrial Chiller | Required |
| Fixed Pin Gauge | Built-in |
| Protection Grade for Electrical Switch-gear | Class Index IP65 |
| Power System Overload & Short-Circuit Protection | Provided |
| Power Supply Required | 380V 50/60Hz @ Three-Phase Sys. |
| Standard | IEC60947 for Electrical System |
| Three-Phase Asynchronous Motor Power | 400W |
| Total Power | 18kVA |
| Construction Size | L1,200 x W1,100 x H1,800mm |
| Weight | 1,200kg |
| Shipment Lead time | 8-10weeks |
| Warranty | 1st Year FREE CHARGE for parts from shipping date + Lifetime services |
| Packaging | Plywood Case ( Standard Export Packaging) |
| Operator Manual | PDF / Printed paper provided |
