20-30CPM Automatic Round Can Body Roll Forming Machine CY400-AT for Tin Can Making
产品编号:
1051325151288582144
Model:
CY400-AT
Operation:
Automatic
Application:
Canbody Roll Forming
Can size:
D75-300(mm), Height less 440mm
Speed:
20-30cpm (Can Size Dependent)
Classification:
keyword:
tin can roll forming machine
tin can roll former
round can roll forming
tin can making machine
canbody roll forming
Product Overview
20-30CPM Automatic Round Can Body Roll Forming Machine CY400-AT for Tin Can Making
☑️1. 8-rounding roller forming machine with function of soft iron, rounder without straight edge.
☑️2. Mitsubishi PLC program control, material table can up and down automatically.
☑️3. Rounder efficiency detected by photoelectric switch, connect with welding machine.
☑️4. Match with semi-automatic seam welder can achieve synchronous production, saving labor cost.
Model | CY400-AT |
Usage | Automatic Roll-forming for Tin Can making |
Operation Mode | Automatic Pneumatic-Drive |
Main Color | Blue+Black |
Output Capacity (CPM) | 20-30CANS/MIN. |
Canbody Diameter Range | 75-300mm |
Canbody Height | less 440mm |
Canbody Thickness Range | 0.2-0.4mm |
Compressed Air | 500L/min @ 0.6Mpa |
Power System Overload & Short-circuit Protection | Provided |
Protection Grade for Electrical Switch-gear Box | Class Index IP65 |
Standard | IEC60947 for Electrical System |
Pneumatic System Supplier | AirTac |
Motor Supplier | SIEMENS |
Electrical Control & Distribution System Supplier | Schneider Electric |
Power Supply Required | 380V AC 50/60Hz Three-phase sys. |
Weight | 450kg |
Construction Size | 2000 x 900 x 1500 mm |
Shipment Lead time: | 4-6 weeks |
Packaging | Plywood Case (Standard Export Packaging) |
Warranty: | 1st Year FREE CHARGE for parts from shipping date + Lifetime services |
Operator Manual & Instruction | PDF / Printed paper provided |
