Automatic External Side Seam Lacquering Machine for Chemical Can Making

产品编号：

1051295504148553728

Operation：

Automatic

Can Size：

D200-400(mm)/D52-190(mm)

Speed：

5-30M./Min.

Line Dimension：

L2,100 x W720 x H1,520 (mm)

Line Weight：

300kg Approx.

Classification：

Chemical Tin Can Making Machine

keyword：

Product Overview

Message

Feature Workflow BOM Technical Parameter YouTube Video PDF Download

Automatic External Side Seam Lacquering Machine for Chemical Can Making

Model	GNWT
Usage	Automatic Lacquer Coating at Food Can External Welding Seam for Anti rust & corrosion
Operation Mode	Automatic
Item Condition	Brand-New
Main Color	Light Grey
Coating Speed	5-30m./Min.
Lacquer Coating Width	10-20mm / 8-15mm
Range of Can Diameter	Ø200-400mm / Ø52-190mm
Coating System Method	Roller Lacquer Contact
Coating Speed Adjustable Function	Provided
VFD Device	Built-in
Pneumatic System Supplier	AirTAC
Power System Overload & Short-Circuit Protection	Provided
Protection Grade for Main Machine	Class Index IP34
Air Requirement & Consumption	0.6Mpa 20L/Min.
Power Supply Required	220V AC 50/60Hz @ 3L+1N+PE (custom-made provided)
Standard	IEC60947 for Electrical System
Power Consumption	0.5kW
Coordinate with Drying Machine	Required
Construction Size	2100 x 720 x 1520mm
Weight	300kg
Shipment Lead time	8-10weeks
Warranty	1st Year FREE CHARGE for parts from shipping date + Lifetime services
Packaging	Plywood Case ( Standard Export Packaging)
Operator Manual	PDF / Printed paper provided

Coating Selection and Application for Can Shape & Coating Basic Usage
Coating Purpose	Coating Type
Primer	Alkyd, expoxy amino, vinyl, etc.
Whitening Coating	Alkyd, acrylic, epoxy ester, polyester, vinyl, etc.
Finishing Coating	Alkyd, acrylate, epoxy ester, epoxy amino, polyester, vinyl, etc.
Coating for can inside	Epoxy novolac, epoxy - acrylic acid, epoxy amino, polybutadiene, phenolic polyester, vinyl, etc.
Coating for weld joint protection	IP2238 and IP2875 from PPG; TS-33/33A and TS-555 from Sakuranomiya Chemical Co., Ltd.
Coating for in-can spraying	Currently, products from ICI (Britain), PPG (America) and Sakuranomiya Chemical (Japan) are in wide use
Coating for in-cover spraying	Coatings from Sakuranomiya Chemical Co., Ltd. are in wide use.
Electrophoretic coating for full open ends	Coatings from PPG (America) and an Italian Company are in wide use
