FH-90ZD up to 60CPM Automatic Can Body Seam Welder Machine
产品编号：
1051324031132590080
Model：
FH18-90ZD
Operation：
Automatic
Application：
Seam Welding
Can size：
D220-300(mm); H250-450(mm)
Speed：
up to 60cpm; up to 26Meters/Minute
Classification：
keyword：
3pc can welder
3piece can welder
tin can making machine
seam welding
side seam welding
Product Overview
FH-90ZD up to 60CPM Automatic Can Body Seam Welder Machine
| Model | FH18-90ZD-42 | FH18-90ZD-60 |
| Item Condition | Brand-New | |
| Operation Mode | Automatic | |
| Feeding Type | Automatic | |
| Welding Type | Resistance Seam Welding | |
| Output Capacity (CPM) | 15-42 cans/min. | 20-60 cans/min. |
| Seaming Rollers Materials | High-grade Alloy Copper | |
| Main Color | White | White |
| Welding Speed | 10-21M./Min. | 10-26M./Min. |
| Range of Can Diameter | Ø220-300mm | |
| Range of Canbody Height | 250-450mm | |
| Support Canbody Materials | Tinplate / Steel-based / Chrome plate | |
| Canbody Thickness Range | 0.25-0.42mm | |
| Seam Welding Overlap | 0.8mm / 1.0mm / 1.2mm (custom-made provided) | |
| Seam Point Distance | 0.5-0.8mm | |
| Applicable Copper Wire Diameter | Ø1.5mm / Ø1.7mm (Purchased Separately Required) | |
| Cooling Water | 12-18°C @ Pressure: 0.4~0.5Mpa Discharge:12L/min | |
| PLC Device | Built-in (Provider MITSUBISHI) | |
| Products Counts Function | Provided (On the Front Control Panel) | |
| Emergency Stop Function | Provided (On the Front Control Panel) | |
| Matching with Industrial Chiller | Required | |
| Fixed Pin Gauge | Built-in | Built-in |
| Protection Grade for Electrical Switch-gear | Class Index IP65 | |
| Power System Overload & Short-Circuit Protection | Provided | |
| Power Supply Required | 380V 50/60Hz @ Three-Phase Sys. (custom-made provided) | |
| Standard | IEC60947 for Electrical System | |
| Total Power | 80kVA | 125kVA |
| Construction Size | 2300 x 1800 x 2000mm | |
| Weight | 2500kg | 2500kg |
| Shipment Lead time | 10+weeks | 10+weeks |
| Warranty | 1st Year FREE CHARGE for parts from shipping date + Lifetime services | |
| Packaging | Plywood Case ( Standard Export Packaging) | |
| Operator Manual | PDF / Printed paper provided | |
