High-position Palletizing Machine for Empty Food Can/beverage Can
产品编号：
1051301098494451712
Operation：
Automatic
Can Size：
D52-153(mm)
Speed：
up to 1,600cpm
Line Dimension：
L15,000 x W3,000 x H3,900(mm)
Line Weight：
4-Ton. Approx.
Classification：
keyword：
Palletizing machine
food can palletizing
food tin can palletizing
food can palletizer
high profile palletizer for food can
Product Overview
High-position Palletizing Machine for Empty Food Can/beverage Can
HFPT series run fully automatically for palletizing or de-palletizing by using pushing and lifting mechanism. With optional configuration, this HFPT series can achieve the function of auto layer pad, pallet dispenser and pallet out feed. By connecting to inline stripper and wrapper, it saves more manpower and increases production efficiency.
| Model | HFPT |
| Operation | Automatic |
| Capacity | 110-1,600cpm (Pallet Size L1,200mm x W1,000mm) |
| Palletizing Type | Pushing & Elevating |
| Pallet Board Auto Feeder | Built-in |
| Programmed PLC Device | Built-in |
| Applicable Products | Various Metal Packing Container, Plastic Container and Glass Container |
| Compressed Air | 0.6MPa |
| Power Supply | Three Phase AC 380V 50Hz |
| Total Power | 11kW |
| Interface | Touch Screen - HMI |
| Control | PLC Controller |
| Motor | Servo and Permanent Magnet Motor |
| Drive | Variable Frequency Inverter (VFD) |
| Conveyor | Scratch Free Chain Boards |
| Overall Dimension | L15,000 x W3,000 x H3,900(mm) |
| Machine Weight | 4,000kg |
|
L15,000 x W3,000 x H3,900(mm) |
|
|
Machine Weight |
4,000kg |
Cans Per Layer
Cans Per Pallet
Net Weight/Pallet
Gross Weight/pallet
| Model | HFPT |
| Operation | Automatic |
| Capacity | 110-1,600cpm (Pallet Size L1,200mm x W1,000mm) |
| Palletizing Type | Pushing & Elevating |
| Pallet Board Auto Feeder | Built-in |
| Programmed PLC Device | Built-in |
| Applicable Products | Various Metal Packing Container, Plastic Container and Glass Container |
| Compressed Air | 0.6MPa |
| Power Supply | Three Phase AC 380V 50Hz |
| Total Power | 11kW |
| Interface | Touch Screen - HMI |
| Control | PLC Controller |
| Motor | Servo and Permanent Magnet Motor |
| Drive | Variable Frequency Inverter (VFD) |
| Conveyor | Scratch Free Chain Boards |
| Overall Dimension | L15,000 x W3,000 x H3,900(mm) |
| Machine Weight | 4,000kg |
| Model | HFPT |
| Operation | Automatic |
| Capacity | 110-1,600cpm (Pallet Size L1,200mm x W1,000mm) |
| Palletizing Type | Pushing & Elevating |
| Pallet Board Auto Feeder | Built-in |
| Programmed PLC Device | Built-in |
| Applicable Products | Various Metal Packing Container, Plastic Container and Glass Container |
| Compressed Air | 0.6MPa |
| Power Supply | Three Phase AC 380V 50Hz |
| Total Power | 11kW |
| Interface | Touch Screen - HMI |
| Control | PLC Controller |
| Motor | Servo and Permanent Magnet Motor |
| Drive | Variable Frequency Inverter (VFD) |
| Conveyor | Scratch Free Chain Boards |
| Overall Dimension | L15,000 x W3,000 x H3,900(mm) |
| Machine Weight | 4,000kg |
| Model | HFPT |
| Operation | Automatic |
| Capacity | 110-1,600cpm (Pallet Size L1,200mm x W1,000mm) |
| Palletizing Type | Pushing & Elevating |
| Pallet Board Auto Feeder | Built-in |
| Programmed PLC Device | Built-in |
| Applicable Products | Various Metal Packing Container, Plastic Container and Glass Container |
| Compressed Air | 0.6MPa |
| Power Supply | Three Phase AC 380V 50Hz |
| Total Power | 11kW |
| Interface | Touch Screen - HMI |
| Control | PLC Controller |
| Motor | Servo and Permanent Magnet Motor |
| Drive | Variable Frequency Inverter (VFD) |
| Conveyor | Scratch Free Chain Boards |
| Overall Dimension | L15,000 x W3,000 x H3,900(mm) |
| Machine Weight | 4,000kg |
| Model | HFPT |
| Operation | Automatic |
| Capacity | 110-1,600cpm (Pallet Size L1,200mm x W1,000mm) |
| Palletizing Type | Pushing & Elevating |
| Pallet Board Auto Feeder | Built-in |
| Programmed PLC Device | Built-in |
| Applicable Products | Various Metal Packing Container, Plastic Container and Glass Container |
| Compressed Air | 0.6MPa |
| Power Supply | Three Phase AC 380V 50Hz |
| Total Power | 11kW |
| Interface | Touch Screen - HMI |
| Control | PLC Controller |
| Motor | Servo and Permanent Magnet Motor |
| Drive | Variable Frequency Inverter (VFD) |
| Conveyor | Scratch Free Chain Boards |
| Overall Dimension | L15,000 x W3,000 x H3,900(mm) |
| Machine Weight | 4,000kg |
| Model | HFPT |
| Operation | Automatic |
| Capacity | 110-1,600cpm (Pallet Size L1,200mm x W1,000mm) |
| Palletizing Type | Pushing & Elevating |
| Pallet Board Auto Feeder | Built-in |
| Programmed PLC Device | Built-in |
| Applicable Products | Various Metal Packing Container, Plastic Container and Glass Container |
| Compressed Air | 0.6MPa |
| Power Supply | Three Phase AC 380V 50Hz |
| Total Power | 11kW |
| Interface | Touch Screen - HMI |
| Control | PLC Controller |
| Motor | Servo and Permanent Magnet Motor |
| Drive | Variable Frequency Inverter (VFD) |
| Conveyor | Scratch Free Chain Boards |
| Overall Dimension | L15,000 x W3,000 x H3,900(mm) |
| Machine Weight | 4,000kg |
