Tinplate Metal Sheet Coating Machine

Tinplate Metal Sheet Coating Machine;
Retail price
0.0
Market price
0.0
Number of views:
1009
Product serial number
Category
Tinplate
Quantity
-
+
Stock:
Model:
TBJ1
Operation:
Automatic
Application:
Metal Sheet Coating
Can size:
Various on Tailor-made
Speed:
Tailor-made Dependent
1
Feature
Parameters
Technical Parameter
PDF Download
YouTube Video

Tinplate Metal Sheet Coating Machine

Coating Process:

To improve corrosion resistance and machinability of tin plates,coating,commonly known yellow,white or transparent coating,is a must. The coating process is normally made up of the following steps,including plate conveying,coating,baking and curing,cooling and stacking. Major equipment includes a coater and a drying oven. The coater applies the wet paint to steel plates which then are sent to the drying oven to be heated in accordance with the pre-set curing curve. The paint,after curing in the drying room,forms a coating (or known as a paint film). The working process of the tinplate coater is as follows:

metal printing process

coating machine layout

Keyword:
coating machine
metal sheet coating machine
metal sheet coating
metal sheet coating line
Scan the QR code to read on your phone
We could not find any corresponding parameters, please add them to the properties table

metal printing process

coating machine layout

Packaging Coatings

Application Area  Primer  White
Basecoat
Clear
Lacquer
Overprint Varnish  Adhesives
Crown Caps  911  19/0018  1670  2000/2000-1  1607-1/1670-2
Aluminum Caps  911-AL  21  303/606  8100  1670
Deep-drawn Cans  911  19  606/909  2000/1800/1900  15
General Draw Cans  911  18  606/909  2000/1800  14
Very Deep-Drawn Cans  911  21  606/909  2100/1800
Ketchup & Luncheon Meat Cans  900/911  9006  202  9003
Beverage Cans  900/911  9006  202  9002
Cans for Milk Powder  900/911  16/0017    902-1
Aerosol Cans  900/900A  16    1100/1600
Stationery Cans  911  19  606/909  1800/1900  15
Three Pieces Cans for Mixed Congee  900  9006  202  9004
Chemical Barrel  900  17  202/505  1100/1600  14
Chemical Solvent Pail  900  11/0016  505  1100/1600/V902
Mooncake Boxes  900/911  17/0018  606/909  2000/1800/1900  waterborne back coating
Tea Caddy  900/911  18/0019  606/909  2000/1800/1900
Electric Cooker  911  18  505  2500-062  901
Thermos Flask  900/911  17  505/606  2000/2500-090  902
Battery Shell  911  21  606/909  1800-1
Fish Cans (2 pieces)  911  21  202/303  2100
Lug Caps  911  19/0021  1670-5  1800/2100
Overcaps for Aerosol-Cans  911  202  2100
Bottoming Caps of Three Pieces Mixed      202/606  303/909
Three-Jaw Lug Caps  911  21  1670-5  2100-1


Stoving Coating for Metal Packaging

Products Category  Products  Features and Applications
Clear & Gold Lacquer  505/606  Basis: modified polyester and amino resin; general gold lacquer;
flexible, deep-drawn, good adhesion to metal substrates, having been used in tin-printing coating area for over 10 years.
202  Basis: modified epoxy resin; general gold lacquer;
high hardness.
Primer Coatings  303  Basis: modified epoxy and amino resin; general lacquer;
transparent, high hardness, good adhesion to metal substrates, soft hand feel.
900/911  Basis: modified polyester and amino resin; general primer; transparent, good adhesion to metal substrates.
White Basecoat  14  Basis: modified polyester and amino resin; general white enamel;
high hardness, embossed.
15  Basis: modified polyester and amino resin; general white enamel;
high -hardness, embossed.
16/0011  Basis: modified polyester and amino resin;
high-hardness, embossed, suitable for UV ink.
17  Basis: modified polyester and amino resin; general white basecoat;
high-hardness, embossed.
18  Basis: modified polyester and amino resin; general white basecoat; high-hardness, embossed; having been used in tin-printing area for over 10 years.
19  Basis: modified polyester and amino resin;
high-hardness, flexible, embossed.
21  Basis: modified polyester and amino resin;
high-hardness, flexible, embossed

Overprint Varnish
1600/1100  Basis: modified polyacrylic and amino resin;
high-hardness, high-glossy, MEK resistant.
1700  Basis: modified polyester and amino resin;
high-hardness, high-glossy, transparent, embossed, MEK resistant.
1800  Basis: modified polyester and amino resin;
hard, glossy, transparent, anti –abrasion, embossed, MEK resistant.
1900  Basis: modified polyacrylic and amino resin;
high-hardness, high-glossy, transparent, anti-abrasion, MEK resistant, embossed.
2000  Basis: modified polyester and amino resin;
high-hardness, high-glossy, anti-abrasion, MEK resistant, embossed.
2100/8100  Basis: modified polyester and amino resin;
high-hardness, high-glossy, anti-abrasion, MEK resistant, deep-drawn.
2500-090  Basis: modified alkyd and amino resin;
high-hardness, high-glossy, anti-abrasion, MEK resistant, deep embossed.
2500-062  Basis: modified polyester polymer and amino resin;
high-hardness, high-glossy, anti-abrasion, MEK resistant, embossed.
9002  Basis: modified polyacrylic and amino resin;
very hard, chemical and MEK resistant, sterilized.
Pearl Paint  8800  Giving the film pearl-like effect, anti-abrasion, high-hardness, MEK resistant, embossed.
Rubber Coating  8810  Very flexible, soft hand feel, like fuzz, embossed.
Gray Coating  901  Economical coating for cans’ interior protection, e.g. electric cooker interior coating.
Clear Lacquer  909  Basis: modified polyester and amino resin;
high glossy, flexible, hard, embossed, MEK resistant.
Three Pieces Cans White Basecoat  9006  Basis: modified polyester and amino resin, white basecoat;
high-glossy, flexible, hard, embossed.
Three Pieces Cans Overprint Vanish  9004/9003/9002  Basis: modified polyacrylic and amino resin; overprint vanish for tin-printing;
transparent, glossy, flexible, hard, embossed, MEK resistant,129°C/90mins sterilized.
