Tailor-Made Automatic Electromagnetic Induction Drying Oven GDCHG for Canbody Making
产品编号：
1051320907210776576
Model：
GDCHG
Operation：
Automatic
Application：
Canbody Seam Drying
Can size：
D52-400(mm)
Speed：
up to 30Meters/Minute
Classification：
keyword：
drying oven
canbody oven
canbody dryer
drying machine
Induction oven
tin can making machine
Product Overview
Tailor-Made Automatic Electromagnetic Induction Drying Oven GDCHG for Canbody Making
| Model | GDCHG-286-8 | GDCHG-180-6 | GDCHG-286-15 |
| Usage | Automatic drying after Internal Power or External Lacquer coating of variety of tin cans ---- Aerosols, food can, beverage can, chemical can | ||
| Operation Mode | Automatic | ||
| Item Condition | Brand-New | ||
| Main Color | Light Grey | ||
| Conveyor Speed | 5-30m./Min. | ||
| Conveyor Type | Flat Chain Drive | ||
| Range of Can Diameter | Ø200 - 400mm | Ø52 - 190mm | Ø200 - 400mm |
| Heating Type | High Frequency Electromagnetic Induction | ||
| Effective Heating | 800mm X 8 (30CPM) | 800mm X 6 (30CPM) | 800mm X 15 (60CPM) |
| Max. Heating Power | 1kw X 8 | 1kw X 6 | 1kw X 15 |
| High Frequency Setting | 80kHz ±10kHz | ||
| Electro Radiation Protective | Fully Covered with Safety Guard | ||
| Effective Sensing Distance | 5-20mm | ||
| Effective Induction Point Width | 40mm | ||
| Powder Drying | 25 sec. @ Can Height: 410mm, CPM 40 | ||
| Temperature Rising Speed | Distance 5mm， 8 sec, 280℃ | Distance 5mm， 6 sec, 280℃ | Distance 5mm， 15 sec, 280℃ |
| Power Supply Required | 380V AC +N ＞10kVA | ||
| Construction Size | L7,500 X W700 X H1,420 (mm) | L6,300 X W700 X H1,420 (mm) | L15,000 X W700 X H1,420 (mm) |
| Weight | 700kg | 850kg | 1,300kg |
| Standard | IEC60947 for Electrical System | ||
| Shipment Lead time | 8-10weeks | ||
| Warranty | 1st Year FREE CHARGE for parts from shipping date + Lifetime services | ||
| Packaging | Plywood Case ( Standard Export Packaging) | ||
| Operator Manual | PDF / Printed paper provided | ||
