GNWT Automatic Can Body External Welding Seam Lacquering Machine
产品编号：
1051321378155618304
Model：
GNWT
Operation：
Automatic
Application：
Lacquering Outer Side Seam Protection
Can size：
D200-400(mm); D52-190(mm)
Speed：
up to 30Meters/Minute
Classification：
keyword：
Lacquering machine
outer side seam protection
external side seam protection
tin can making machine
Product Overview
GNWT Automatic Can Body External Welding Seam Lacquering Machine
Lacquer outside seam protection
|
Model |
GNWT |
|
Usage |
Automatic Lacquer Coating |
|
Operation Mode |
Automatic |
|
Item Condition |
Brand-New |
|
Main Color |
Light Grey |
|
Coating Speed |
5-30m./Min. |
|
Lacquer Coating Width |
10-20mm / 8-15mm |
|
Range of Can Diameter |
Ø200-400mm / Ø52-190mm |
|
Coating System Method |
Roller Lacquer Contact |
|
Coating Speed Adjustable Function |
Provided |
|
VFD Device |
Built-in |
|
Pneumatic System Supplier |
AirTAC |
|
Power System Overload & Short-Circuit Protection |
Provided |
|
Protection Grade for Main Machine |
Class Index IP34 |
|
Air Requirement & Consumption |
0.6Mpa 20L/Min. |
|
Power Supply Required |
220V AC 50/60Hz @ 3L+1N+PE (custom-made provided) |
|
Standard |
IEC60947 for Electrical System |
|
Power Consumption |
0.5kW |
|
Coordinate with Drying Machine |
Required |
|
Construction Size |
L2,100 x W720 x H1,520mm |
|
Weight |
300kg |
|
Shipment Lead time |
8-10weeks |
|
Warranty |
1st Year FREE CHARGE for parts from shipping date + Lifetime services |
|
Packaging |
Plywood Case ( Standard Export Packaging) |
|
Operator Manual |
PDF / Printed paper provided |
| Coating Selection and Application for Can Shape & Coating Basic Usage | |
| Coating Purpose | Coating Type |
| Primer | Alkyd, expoxy amino, vinyl, etc. |
|
Whitening Coating |
Alkyd, acrylic, epoxy ester, polyester, vinyl, etc. |
|
Finishing Coating |
Alkyd, acrylate, epoxy ester, epoxy amino, polyester, vinyl, etc. |
|
Coating for can inside |
Epoxy novolac, epoxy - acrylic acid, epoxy amino, polybutadiene, phenolic polyester, vinyl, etc. |
| Coating for weld joint protection | IP2238 and IP2875 from PPG; TS-33/33A and TS-555 from Sakuranomiya Chemical Co., Ltd. |
| Coating for in-can spraying | Currently, products from ICI (Britain), PPG (America) and Sakuranomiya Chemical (Japan) are in wide use |
| Coating for in-cover spraying | Coatings from Sakuranomiya Chemical Co., Ltd. are in wide use. |
| Electrophoretic coating for full open ends | Coatings from PPG (America) and an Italian Company are in wide use |
