FH18-38 20-80CPM Semi-Auto Can Body Seam Welder Machine

产品编号：

1051322991050055680

Model：

FH18-38

Operation：

Semi-Automatic

Application：

Seam Welding

Can size：

D38-45(mm); H70-320(mm)

Speed：

20-80cpm; 6-18Meters/Minute

Classification：

Welding

keyword：

seam welding

Product Overview

Message

Feature Workflow BOM Technical Parameter YouTube Video PDF Download

FH18-38 20-80CPM Semi-Auto Can Body Seam Welder Machine

Model	FH18-38
Usage	Canmaking Body Seam Welding for Dia. Range from Ø38-45mm
Item Condition	Brand-New
Operation Mode	Semi-Automatic
Feeding Type	Rear Manual
Welding Type	Resistance Seam Welding
Output Capacity (CPM)	20-80cans/min. (Operator Dependent)
Seaming Rollers Materials	High-grade Alloy Copper
Main Color	White
Welding Speed	6-18M./Min.
Range of Can Diameter	Ø38-45mm
Range of Canbody Height	70-320mm
Support Canbody Materials	Tinplate / Steel-based
Canbody Thickness Range	0.18-0.25mm
Seam Welding Overlap	0.4mm / 0.6mm
Seam Point Distance	0.5-0.8mm
Applicable Copper Wire Diameter	Ø1.38mm (Purchased Separately Required)
Cooling Water	12-18°C @ Pressure: 0.4~0.5Mpa Discharge:7L/min
PLC Device	Built-in (Provider MITSUBISHI)
Products Counts Function	Provided (On the Front Control Panel)
Emergency Stop Function	Provided (On the Front Control Panel)
Matching with Industrial Chiller	Required
Fixed Pin Gauge	Built-in
Protection Grade for Electrical Switch-gear	Class Index IP65
Power System Overload & Short-Circuit Protection	Provided
Power Supply Required	380V 50/60Hz @ Three-Phase Sys.
Standard	IEC60947 for Electrical System
Three-Phase Asynchronous Motor Power	400W
Total Power	18kVA
Construction Size	L1,200 x W1,100 x H1,800mm
Weight	1,200kg
Shipment Lead time	8-10weeks
Warranty	1st Year FREE CHARGE for parts from shipping date + Lifetime services
Packaging	Plywood Case ( Standard Export Packaging)
Operator Manual	PDF / Printed paper provided

Model	FH18-38
Usage	Canmaking Body Seam Welding for Dia. Range from Ø38-45mm
Item Condition	Brand-New
Operation Mode	Semi-Automatic
Feeding Type	Rear Manual
Welding Type	Resistance Seam Welding
Output Capacity (CPM)	20-80cans/min. (Operator Dependent)
Seaming Rollers Materials	High-grade Alloy Copper
Main Color	White
Welding Speed	6-18M./Min.
Range of Can Diameter	Ø38-45mm
Range of Canbody Height	70-320mm
Support Canbody Materials	Tinplate / Steel-based
Canbody Thickness Range	0.18-0.25mm
Seam Welding Overlap	0.4mm / 0.6mm
Seam Point Distance	0.5-0.8mm
Applicable Copper Wire Diameter	Ø1.38mm (Purchased Separately Required)
Cooling Water	12-18°C @ Pressure: 0.4~0.5Mpa Discharge:7L/min
PLC Device	Built-in (Provider MITSUBISHI)
Products Counts Function	Provided (On the Front Control Panel)
Emergency Stop Function	Provided (On the Front Control Panel)
Matching with Industrial Chiller	Required
Fixed Pin Gauge	Built-in
Protection Grade for Electrical Switch-gear	Class Index IP65
Power System Overload & Short-Circuit Protection	Provided
Power Supply Required	380V 50/60Hz @ Three-Phase Sys.
Standard	IEC60947 for Electrical System
Three-Phase Asynchronous Motor Power	400W
Total Power	18kVA
Construction Size	L1,200 x W1,100 x H1,800mm
Weight	1,200kg
Shipment Lead time	8-10weeks
Warranty	1st Year FREE CHARGE for parts from shipping date + Lifetime services
Packaging	Plywood Case ( Standard Export Packaging)
Operator Manual	PDF / Printed paper provided

welder machine specification cover
