Metal Tinplate Sheet Six Color Printing Machine

Metal Tinplate Sheet Six Color Printing Machine;

产品编号:

1051327821055352832

Model:

YTJS-6

Operation:

Automatic

Application:

Six Color Metal Printing

Can size:

Various on Tailor-made

Speed:

75-85spm.

Classification:

keyword:

METAL SHEET SIX COLOR PRINTING MACHINE

METAL SHEET SIX COLOR PRINTER

metal sheet printing process

metal printing line


Product Overview

Message
Feature Workflow BOM Technical Parameter YouTube Video PDF Download

Metal Tinplate Sheet Six Color Printing Machine

6-color metal printing

metal printing process

Technical performance:



The main transmission gear is located in the machine's protective cover.



Three printing drum vertical arrangement, easy to operate;



Printed rollers are imported precision bearing support to ensure that the drum rotation accuracy:



By the roller pressure adjustment structure advanced, easy to operate:



Adopting shaftless transmission technology, each color group has the independence of each other, so that the drum can be mounted and wiped at the same time;



The use of synchronous transmission between the color group technology, through the virtual spindle as a reference, to achieve high-precision synchronization



Printed outlets strong, clear;



Roller with a hard liner way,



Closing the cam with a high point, reliable positioning, overprint accurate:



Plate cylinder with alcohol dampening, printed matter brightly colored ink;



By version of the roller, cylinder clutch cylinder drive, simple structure, reliable work:



Water roller, ink roller by a separate inverter motor drive, stepless speed regulation, synchronization with the host to achieve speed tracking:



Scientific and reasonable ink rollers arranged to ensure that the system for ink quality;



Inking system and dampening system transmission can be disconnected from the host machine according to the need to avoid the dry wear of the roller:



Man-machine interface, intuitive screen, easy to grasp, easy to operate:



Feeding machine and the synchronization of the host can not stop machine electric regulation, effectively shorten the auxiliary time



Using fixed-point, quantitative, regular lubrication system, full lubrication without oil leakage.



Technical Parameters:

Max.Sheet Size
1,145X965mm
Min. Sheet Size
712X508mm
Thickness of Sheet
0.16-0.50mm
Max. Printing Area
1,135X945mm
Plate Size
1,160X1,040X0.3mm
Blanket Size

1,175X1,135X1.9mm

Gripper Edge Size
5mm
Max. Printing Speed
6,000pieces / hour
Printing speed
 According to the printing parameters
Max.Material Weight
2T
Machine Size(L*W*H)
L21,530 X W3,700 X H2,460mm
(with inspection table)
L18,580 X W3,700 X H2,460mm
(without inspection table)




6-color metal printing

metal printing process



Color-printed metal, which is bright-colored, shiny and rust-resistance, can be used in replacement of paper labels to make metal tin cans look more beautiful and attractive to consumers, prevent fakery and indicate product instructions. With the use of large quantities of LTS and TFS plates, color-printed metal has become an important choice for consuming such plates, and there has been a rapid increase in application of label printing to can bodies and can covers.



Coatings used for color printing including primers such as alkyd, acrylic, epoxy amino, epoxy ester, polyester, and vinyl as well as white coatings and polishing vanishes. Besides, there are also printing inks of various colors.

6-color metal printing

metal printing process



Color-printed metal, which is bright-colored, shiny and rust-resistance, can be used in replacement of paper labels to make metal tin cans look more beautiful and attractive to consumers, prevent fakery and indicate product instructions. With the use of large quantities of LTS and TFS plates, color-printed metal has become an important choice for consuming such plates, and there has been a rapid increase in application of label printing to can bodies and can covers.



Coatings used for color printing including primers such as alkyd, acrylic, epoxy amino, epoxy ester, polyester, and vinyl as well as white coatings and polishing vanishes. Besides, there are also printing inks of various colors.

6-color metal printing

metal printing process



Color-printed metal, which is bright-colored, shiny and rust-resistance, can be used in replacement of paper labels to make metal tin cans look more beautiful and attractive to consumers, prevent fakery and indicate product instructions. With the use of large quantities of LTS and TFS plates, color-printed metal has become an important choice for consuming such plates, and there has been a rapid increase in application of label printing to can bodies and can covers.



Coatings used for color printing including primers such as alkyd, acrylic, epoxy amino, epoxy ester, polyester, and vinyl as well as white coatings and polishing vanishes. Besides, there are also printing inks of various colors.

6-color metal printing

metal printing process



Color-printed metal, which is bright-colored, shiny and rust-resistance, can be used in replacement of paper labels to make metal tin cans look more beautiful and attractive to consumers, prevent fakery and indicate product instructions. With the use of large quantities of LTS and TFS plates, color-printed metal has become an important choice for consuming such plates, and there has been a rapid increase in application of label printing to can bodies and can covers.



Coatings used for color printing including primers such as alkyd, acrylic, epoxy amino, epoxy ester, polyester, and vinyl as well as white coatings and polishing vanishes. Besides, there are also printing inks of various colors.

6-color metal printing

metal printing process



Color-printed metal, which is bright-colored, shiny and rust-resistance, can be used in replacement of paper labels to make metal tin cans look more beautiful and attractive to consumers, prevent fakery and indicate product instructions. With the use of large quantities of LTS and TFS plates, color-printed metal has become an important choice for consuming such plates, and there has been a rapid increase in application of label printing to can bodies and can covers.



Coatings used for color printing including primers such as alkyd, acrylic, epoxy amino, epoxy ester, polyester, and vinyl as well as white coatings and polishing vanishes. Besides, there are also printing inks of various colors.
